PUMP PTOC-150-1000-B 1000 BELT 1.5" X 1.25" 1" STUB SHAFT
Item #:
465-0485061
Manufacturer Item: 48506
Manufacturer:
ACE Pump
1406.59
Each
Quantity:
The ACE PUMP PTOC-150-1000-B is a PTO belt-driven centrifugal pump designed for high performance and smooth operation in tractor-mounted PTO applications. It features a 1-1/2" suction port and a 1-1/4" discharge port, both with female NPT threads. The pump is constructed with cast iron and a Viton® seal. It's designed for a 1000 RPM drive shaft and can achieve a maximum flow rate of 100 GPM and a maximum pressure of 110 PSI.
PTO
SIZE
1 1/2" X 1 1/4"
RPM
1000
Item#:
050-2001501
Manufacturer Item:
LS150B/C
Manufacturer:
BANJO
Your Price:
39.88
Each
Item#:
029-1312125
Manufacturer Item:
HB125-90
Manufacturer:
BANJO
Your Price:
2.43
Each
Item#:
026-3001253
Manufacturer Item:
752388
Your Price:
5.36
FOOT
| No. | Part No. | Item Description | Qty Req. | ||
| 1 |
SHAFT 1"
|
1 |
316.34
Each
|
|
|
| 10 |
BALL FOR QC
|
3 |
1.57
Each
|
|
|
| 11 |
SPRING
|
1 |
10.80
Each
|
|
|
| 17 |
INTERNAL SNAP RING
|
2 |
4.53
Each
|
|
|
| 19 |
EXT SNAP RING
|
1 |
1.22
Each
|
|
|
| 20 |
BEARING
|
2 |
45.99
Each
|
|
|
| 21 |
SPACER
|
1 |
33.97
Each
|
|
|
| 24 |
PTO DRIVE SHAFT BRG HSG
|
1 |
190.22
Each
|
|
|
| 24 |
HOUSING W/FEET
|
1 |
275.23
Each
|
|
|
| 25 |
SHAFT 6 SPLINE QC
|
1 |
339.33
Each
|
|
|
| 29 |
PULLEY 11.6/10GR
|
1 |
267.57
Each
|
|
|
| 31 |
10 GROOVE BELT - PTOC-150-600
|
1 |
57.83
Each
|
|
|
| 31 |
10 GROOVE BELT - PTOC-150-1000
|
1 |
57.83
Each
|
|
|
| 32 |
PIPE PLUG 1/8"
|
3 |
0.70
Each
|
|
|
| 32 |
PLUG SS 1/8"
|
3 |
4.53
Each
|
|
|
| 33 |
VOLUTE 1 1/2" X 1 1/4" CI
|
3 |
287.77
Each
|
|
|
| 34 |
LOCKNUT 3/8" NF
|
1 |
2.26
Each
|
|
|
| 35 |
WASHER 3/8" SS
|
1 |
1.57
Each
|
|
|
| 36 |
IMPELLER WITH KEYWAY CI
|
1 |
206.95
Each
|
|
|
| 36 |
IMPELLER
|
1 |
82.22
Each
|
|
|
| 37 |
VOLUTE SEAL O-RING
|
1 |
6.79
Each
|
|
|
| 38 |
HD SEAL
|
1 |
153.29
Each
|
|
|
| 38 |
SEAL
|
1 |
44.59
Each
|
|
|
| 38A |
SHAFT O-RING
|
1 |
1.05
Each
|
|
|
| 41 |
FRAME F/IDLER A
|
1 |
302.40
Each
|
|
|
| 44 |
SLINGER
|
1 |
2.09
Each
|
|
|
| 45 |
INT SNAP RING
|
2 |
1.92
Each
|
|
|
| 46 |
BEARING
|
2 |
17.77
Each
|
|
|
| 47 |
EXTERNAL SNAP RING
|
2 |
1.05
Each
|
|
|
| 48 |
SPACER
|
1 |
5.40
Each
|
|
|
| 49 |
IMPELLER KEY 1/8"
|
1 |
1.22
Each
|
|
|
| 50 |
SS SHAFT 5/8" DIA
|
1 |
117.76
Each
|
|
|
| 51 |
KEY 3/16 X 3/16 X 1 1/4
|
1 |
1.57
Each
|
|
|
| 52 |
1.35" PULLEY
|
1 |
75.25
Each
|
|
|
| 52 |
1.7" PULLEY
|
1 |
75.25
Each
|
|
|
| 53 |
5/16" ALLEN HD SETSCREW
|
2 |
1.05
Each
|
|
|
| 54 |
TORSION SPRING
|
1 |
22.99
Each
|
|
|
| 55 |
IDLER ARM
|
1 |
86.40
Each
|
|
|
| 56 |
EXTERNAL SNAP RING
|
1 |
1.92
Each
|
|
|
| 57 |
5/8" SPACER
|
10 |
26.83
Each
|
|
|
| 58 |
IDLER BEARING & ROLLER
|
1 |
62.71
Each
|
|
|
| 59 |
5/8"X2 1/8"HX HD CAP SCREW
|
1 |
7.14
Each
|
|
|
| 60 |
BELT & SHAFT GUARD
|
1 |
125.07
Each
|
|
|
| # |
PUMP ONLY 1 1/2" X 1 1/4"
|
1 |
514.82
Each
|
|
|
| RK |
REPAIR KIT
|
1 |
52.96
Each
|
|
|
| 12 |
COLLAR/BALL RETAINER SLEEVE
|
1 |
29.26
Each
|
|
