The Hypro 9306C + S (3U) Series hydraulic driven centrifugal pump achieves a max of 322gpm and 140psi.
Hydraulic motor drive (for open center, closed center and load-sensing systems)
Max. fluid temperature: 140°F/60°C
Available in cast iron and 316 stainless steel for extended pump life
Impeller: Nylon (cast iron models); polypropylene (stainless steel models); (GTX available)
Motor: internal gear gerotor
Hydraulic ports: 1⁄2" NPT inlet, 3⁄4" NPT outlet
Max. motor psi: 3000 (bar: 207)
Pump seals: Cast Iron models – Viton® / Ceramic standard; LifeGuard silicon carbide (B) available; Stainless Steel models – LifeGuard silicon carbide
Hydraulic motor seal: double-lip Teflon®
Weight: 33 lbs./15 kg
Item#:
007-0093065
Manufacturer Item:
9306C-HM5C-3U
Manufacturer:
HYPRO
Your Price:
1513.41
Each
The Hypro 9303C & 9303S Series hydraulic motor driven, cast iron and stainless steel centrifugal pump achieves a max of 147gpm and 145psi.
Available in cast iron and 316 stainless steel for extended pump life
Hydraulic motor drive (for open center, closed center and load-sensing systems)
220 x 200 Universal Flange available (U)
Max. fluid temperature: 140°F/60°C
Impeller: Cast Iron models – Nylon; (GTX available) Stainless Steel models – Polypropylene
Motor: internal gear gerotor
Pump seals: Cast Iron models – Viton ® /ceramic standard; Life Guard silicon carbide (B) available; Stainless Steel models – Life Guard silicon carbide standard
Hydraulic motor seal: double-lip Teflon ®
Weight: 26 lbs./11.8 kg
Item#:
007-0930313
Manufacturer Item:
9303C-HM1C-U
Manufacturer:
HYPRO
Your Price:
1208.90
Each
The Hypro 9303C & 9303S Series hydraulic motor driven, cast iron and stainless steel centrifugal pump achieves a max of 147gpm and 145psi.
Available in cast iron and 316 stainless steel for extended pump life
Hydraulic motor drive (for open center, closed center and load-sensing systems)
220 x 200 Universal Flange available (U)
Max. fluid temperature: 140°F/60°C
Impeller: Cast Iron models – Nylon; (GTX available) Stainless Steel models – Polypropylene
Motor: internal gear gerotor
Pump seals: Cast Iron models – Viton ® /ceramic standard; Life Guard silicon carbide (B) available; Stainless Steel models – Life Guard silicon carbide standard
Hydraulic motor seal: double-lip Teflon ®
Weight: 26 lbs./11.8 kg
Item#:
007-0930346
Manufacturer Item:
9303C-HM4C-U
Manufacturer:
HYPRO
Your Price:
1208.90
Each
The Hypro 9304C-HM5C is a hydraulically-driven centrifugal pump, commonly used in agricultural sprayers like the Willmar Eagle/Ranger. It features a cast iron housing, a nylon impeller, and Viton/ceramic seals. The pump has a 2-inch NPT inlet and a 1.5-inch NPT outlet, and it is designed for open or closed center hydraulic systems.
Your Price:
1479.77
Each
The Hypro 9305C-HM3C is a hydraulically driven, cast iron centrifugal pump with a maximum flow rate of 182 gallons per minute (GPM) and a maximum pressure of 156 PSI. It's designed for agricultural and industrial spraying and fluid transfer applications. The pump features a 2" NPT inlet and a 1-1/2" NPT outlet.
Your Price:
1926.98
Each
The Hypro 9306C-HM5C-U is a hydraulic-driven centrifugal pump designed for agricultural and industrial spraying applications. It features a cast iron housing, nylon impeller, and Viton/ceramic seals (Life Guard silicon carbide available). Key specifications include a maximum flow rate of 212 GPM, a maximum pressure of 140 PSI, and a maximum fluid temperature of 140°F (60°C). The pump is designed for open center, closed center, and load-sensing hydraulic systems.
Item#:
007-0930614
Manufacturer Item:
9306C-HM5C-U
Manufacturer:
HYPRO
Your Price:
1393.43
Each
The Hypro 9306C-HM5C is a hydraulically driven centrifugal pump with a maximum flow rate of 212 GPM and a maximum pressure of 140 PSI. It features a cast iron housing, a nylon impeller, and a hydraulic motor (for open, closed, and load-sensing systems).
Your Price:
1344.35
Each
The Hypro repair kit 3430-0500 is a seal and O-ring kit for the 9305C series centrifugal pumps. It includes a mechanical seal, an O-ring, and a rubber gasket. The kit is designed for use in both open and closed hydraulic systems.
Item#:
007-3430500
Manufacturer Item:
3430-0500
Manufacturer:
HYPRO
Your Price:
62.00
Each
The Hypro kit 3430-0659 is a Viton seal repair kit designed for Hypro 1542P series transfer pumps, specifically the 1542P-3SP and 1542P-5SP models. The kit includes essential components for sealing and repairing the pump, including a diffuser gasket, pump body O-ring, flapper valve, seal O-ring, and mechanical seal. Viton, a type of fluoroelastomer, is used in this kit for its excellent resistance to chemicals and high temperatures.
Item#:
007-3430659
Manufacturer Item:
3430-0659
Manufacturer:
HYPRO
Your Price:
116.58
Each
The Ace Pumps repair kit RK-BAC-75-HYD-300-L is designed for Ace Pumps' 300 Series hydraulic motors. Specifically, it's a repair kit for the 300 series motor, and it's identified by the part number 41362. The kit includes components like a Teflon lip seal, a seal support spacer, O-rings, and thread seals.
Item#:
465-0413621
Manufacturer Item:
41362
Manufacturer:
ACE Pump
Your Price:
92.50
Each
The ACE FMC-75-HYD-204 is a hydraulic-driven, polypropylene centrifugal pump with a 1" NPT inlet and 3/4" NPT outlet. It requires a 4 GPM (15.1 LPM) hydraulic flow for operation on closed or open center systems. The pump has a maximum flow rate of 25 GPM and a maximum pressure of 100 PSI. It is commonly used for agricultural and industrial spraying applications.
Item#:
465-0497751
Manufacturer Item:
49775
Manufacturer:
ACE Pump
Your Price:
814.61
Each
The Ace FMC-75-HYD-206 is a hydraulically driven centrifugal pump designed for agricultural and industrial spraying. It features a polypropylene body, a stainless steel shaft, and a Viton® Carbon/Ceramic mechanical seal (with an optional Silicon Carbide seal). The pump has a maximum flow rate of 27 gpm and a maximum pressure of 100 psi. It requires a hydraulic flow of 7 gpm on both closed and open systems.
Item#:
465-0497756
Manufacturer Item:
49777
Manufacturer:
ACE Pump
Your Price:
814.61
Each
